Teltonika FMB640 to terminal GNSS, GSM do zastosowań PROFESJONALNYCH. FMB640 jest przeznaczony do kompleksowych rozwiązań, w których jedno urządzenie może wykonywać wiele zadań.

MODULE
Name Teltonika TM2500
Technology GSM/GPRS/GNSS
GNSS
GNSS GPS, GLONASS, GALILEO, BEIDOU, SBAS, QZSS, DGPS
Receiver 33/99 acquisition channels
Tracking sensitivity -165 dBM
Accuracy < 2.5m CEP
Hot start < 1 s
Warm start < 25 s
Cold start < 35 s

CELLULAR
Technology GSM/GPRS
2G bands Quad-band 850/900/1800/1900 MHz
GPRS GPRS Mobile Station Class B
Data transfer GPRS Multi-Slot Class 12 (up to 240 kbps)
Data support SMS (text/data)

POWER
Input voltage range 10 – 30 V DC with overvoltage protection
Internal Back-up battery 550 mAh Ni-Mh, 8.4 V battery
Power consumption At 12V < 7 mA(Deep Sleep)
At 12V < 12 mA(Online Deep Sleep)
At 12V < 28 mA(GPS Sleep)
At 12V < 65 mA(nominal)
At 12V <120 mA (GPRS)

INTERFACE
Digital Inputs 4
Digital Outputs 4
Analog Inputs 4
1-Wire 1
RS232 2
RS485 1
CAN J1939 2
J1708 1
K-line 1
GNSS antenna External High Gain
Cellular antenna External High Gain
USB 2.0 Mini-USB
LED indication 2 status LED lights
SIM 2x SIM Card (Dual-SIM)
Memory 2MB internal flash memory and external Micro SD card up to 32 GB

PHYSICAL SPECIFICATION
Dimensions 104.1 x 76.8 x 31.5 mm (L x W x H)
Weight 197 g

OPERATING ENVIRONMENT
Operating temperature
(without battery) -40 °C to +85 °C
Storage temperature
(without battery) -40 °C to +85 °C
Operating humidity 5% to 95% non-condensing
Battery storage temperature -20 °C to +45 °C
Ingress Protection Rating IP41

FEATURES
Sensors Accelerometer
Scenarios Green/Eco Driving, Over Speeding detection, Jamming detection, Excessive Idling detection, Towing detection, Crash detection, Immobilizer, iButton Read Notification, Auto Geofencing, Manual Geofencing, Trip detection, Odometer, Fuel counter, GNSS Unplug Detection, DDD download and Tacho online data, Offline tracking, Voice call
Supported peripherals RFID RS232, RFID 1-Wire, iButton 1-Wire, Temperature 1-Wire, Continental tire pressure measurement sensor
Sleep modes GPS Sleep, Online Deep Sleep, Deep Sleep
Configuration and firmware update FOTA Web, FOTA, Teltonika Configurator
SMS Configuration, Events, DOUT control, Debug
GPRS commands Configuration, DOUT control, Debug
Time Synchronization GPS, NITZ, NTP
Fuel monitoring LLS (Analog), Digital LLS (RS232, RS485), LV-CAN200, ALL-CAN300, CAN-CONTROL, CAN FMS (J1939, J1708), Ultrasonic level sensor
Ignition detection Digital Input, Accelerometer, External Power Voltage
RS232 Modes Log Mode, NMEA, LLS, LCD, RFID HID/MF7, Garmin FMI, TCP ASCII/Binary, TCP ASCII/Binary (Buffered), Rec to LCD, Atol Tachograph, UL202-2 Fuel Sensor, TSM232 Sattelite backup, Carrier Freezer
RS485 Modes Silent, Log Mode, NMEA, LLS, TCP ASCII/Binary, TCP ASCII/Binary (Buffered)

CERTIFICATION & APPROVALS
Regulatory CE/RED, E-Mark, EAC, RoHS, REACH
